Creating a communication

You can use communications or notices to send hold notices to issue legal holds, questionnaires, follow-up communications, or anything else you need to send to a custodian or group of specified custodians regarding their involvement in the project or hold.

Before creating a communication, you must add email settings. See the following:

• Adding email settings
• Gmail API
• Graph API

Create custom communications using the rich text editor and email merge fields. For more information, see Email merge fields.

To create a communication:

1. From the Projects tab > Project console > Manage Project, click Create Communication.

   The Create New Communication dialog appears.


2. Select one of the following options:
   • Communication Type—select a communication type. Default communications types include General Hold Notice, Release Notice, Email Acknowledgement, and Alert Group. For more information, see Communication detail layout fields.
   • Create From:
     • Template—create a new communication using an existing template. Legal Hold only displays templates with the same type as the selected Communication Type. When creating a communication from a template, the following items carry over with the following pre-populated field information.
       • Name
       • Type
       • Description
       • Acknowledgment Required
       • Attachments
       • Questionnaire
       • Portal Content
       • Email Send As
       • Email Subject
       • Email Body
       • Automatic Reminders
       • Email Reminder Subject
       • Email Reminder Body
       • Automatic Escalations
       • Email Escalation Body
       • BCC Email SubjectFor admin's adding up email settings, seeFor admin's adding up email settings, see
       Note: Legal Hold respects secured template items, so not all template items may carry over, depending on the item-level permissions.
     • Blank Communication—create a new communication from scratch.
3. Click Create.
4. Complete the fields on the New Communication layout. See Communication detail layout fields.
5. Click Save. The Communication details appears. See Communication details.
6. (Optional) From the communication details, click Edit to update more communication detail fields. See Communication detail layout fields.
7. Click Save. The new communication appears in the Project Details Communication tab.

Communication detail layout fields

The Create communication layout contains the following fields:

Detail tab

• Name—the communication name.
• Type—the communication type. Click Add to add a new type. Legal Hold ships with several generic communication types.
• Send To for Approval—the admin that communications need to be approved by before they are sent to custodians. This only appears if you do not have approval permissions. For more information, see Securing a project.
• Response Due Date—the communication response deadline. This value potentially updates the Past Due Communication value on the Custodians sub tab of the Project layout.

  Note: Exceeding the Response Due Date on a communication does not trigger an alert such as a legal hold communication or email.

• Description—(Optional) a communication description.
• Save As Template—select checkbox to make this communication available as a template.
• Project—the project to which the communication is associated.

Email tab

• Send As Alias—only available for SMTP. The specified email address you want the communication to be sent from. This feature allows you to send a communication on someone else's behalf. For example, a junior attorney may send the email, but may want the email to appear as coming from the general counsel. If no email address is entered, the email address set From Email Address field of the Legal Hold Settings. For more information, see Adding Outgoing Email settings.

  Note: To use Send As Alias, you must select SMTP as the Email Processor Type when adding email settings. For more information, see Adding Outgoing Email settings.

• Subject—the subject that appears in the email.
• Body—the email body that appears in the communication. The [PortalLink] merge field is required if any of the following conditions are met:
  • Acknowledgement required is set to Yes.
  • There is any text in the Portal Detail.
  • There is a questionnaire included.
  • There is a linked attachment included.

See Using the editor window and Email merge fields.

Portal Content tab

• Acknowledgement Required—select Yes to require an acknowledgement and be able to schedule reminders and escalations for a questionnaire attached to a communication.

  Note: No portal link needs to be present in the communication body when creating a General Hold notice and the Acknowledgement Required is set to No, and also does not have an attached questionnaire.
• Is Legal Hold—select Yes or No to visually indicate whether the communication is a legal hold in the Custodian portal. If this field is set to Yes, the Global Reminder is enabled.
• Attachments—click ellipses button to attach an existing file from the Attachment Library. See Attachments library.
  • You can add attachments to the portal after a hold notice has been sent out.
  • We recommend notifying custodians with a follow-up communication after adding new documents to the portal.
• Questionnaire—click ellipses button to select an existing questionnaire from the Questionnaire Library. See Question types.
  • Click Add to create a new questionnaire. See To create a questionnaire:.
  • No portal link needs to be present in the communication body when creating a General Hold notice no questionnaire is selected, and the Acknowledgement Required field is set to No.

• Use Email Body for Portal Detail—select Yes or No to copy the email body to used as the portal content. If set to Yes, the HTML editor is removed and the content in the email body is duplicated as the portal content. If set to No, the HTML editor is available and the content in the editor is used in the custodian portal.
• Portal Detail—portal content for this communication. See Using the editor window.

Reminder & Escalation tab

• Reminder
  • Automatic Reminders—select Yes for Legal Hold to send automatic reminder emails to custodians that have not yet acknowledged the communication or completed the associated questionnaire. Select No to disable automatic reminders to the custodians who have not completed the required acknowledgement or questionnaire.
  • Allotted Reminders—the number of reminders allowed for this communication until the reminders expire and, if selected, escalations begin to be sent.
  • Reminder Interval (in days)—the number of days between each reminder. For example, if you enter 7, reminders are sent weekly.

    Note: The interval clock starts counting down from the time the communication was sent or from the last sent reminder time.
  • Reminder Subject—the email subject that appears in the reminder email.
  • Reminder Body—the email message that appears in the reminder email. See Using the editor window.
• Escalation
  • Automatic Escalations—select Yes to indicate whether Legal Hold should send an escalated communication, typically to a custodian’s manager, often after automatic reminders have expired. Legal Hold sends the escalation email one iteration after the scheduled reminder or reminders ends. For example, if an automatic reminder is configured to send a total of two reminders every five days, the first automatic escalation would get sent on the 15th day, five days after the last automatic reminder was sent to the assigned custodian, or custodians. Select No to disable automatic escalations.
  • Allotted Escalations—the number of escalations allowed for this communication.
  • Escalation Interval (days)—the number of days between each escalation. For example, if you enter 7, reminders are sent weekly.

    Note: The interval clock starts counting down from the time the communication was sent or from the last sent escalation time.
  • Escalation Recipient—select the recipient of the escalations, and by default, sends an escalation to the entity's designated manager. You can also select a manager, project owner, or other entity. Click Manage to add, update, or remove recipients. If no recipient is entered, the escalation is sent to project owner.
  • Other Entity Recipient—select an existing entity within the workspace to receive escalations. For example, if you want someone to receive all escalations, confirm they are an entity within the workspace and select them as the escalation recipient.
    Click Add to create a new custodian to send the escalation to.
  • CC Recipients—sends an escalation to entities that need to be included in addition to the escalation recipient that was previously selected. Click the ellipsis button next to CC Recipients to send the escalation to multiple recipients.
  • Escalation Subject—the email subject that appears in the escalation emails.
  • Escalation Body—the message that appears in the email. See Using the editor window.

    Note: The merge field on the escalation should be the custodian name, not the manager name.

Summary BCC tab

The BCC tab allows you to send a customized email to any custodian or group in Legal Hold. The email includes the text you specify, a line break, the original communication that's sent to other people through non-BCC, and an attachment listing all the people the original communication was sent to.

Note: The Legal Hold BCC feature is not a "true" BCC to all of the original emails, but rather a unique email that goes out once with the associated set of hold notices and consolidates the details from many emails into a single email.

• BCC Recipients—the custodian that you want to send the BCC email to. See Creating legal hold entities.
• BCC Subject—the subject that appears in the email.
• BCC Body—the message that appears in the email. See Using the editor window.

Note: People you send BCC emails to aren't included in Legal Hold reports.

Communication types

Relativity Legal Hold projects include multiple communications that are sent through Relativity to custodians. These communications range from a general legal hold notice to a release notice. These communications have different purposes such as notifying a custodian about being added to a legal hold, answering questions regarding the hold, and being released from the hold. The recipients of the communications can be legal hold custodians, data stewards, executives, or legal team members.

Communications can be scheduled for automatic reminders and escalations, particularly when a custodian isn't responsive, you would schedule the automation from the communication details. For more information, see Legal hold reminders.

General notice

The general notice is sent to active custodians in the project and describes the background, claims, and the position of the entity involved in the legal matter. It also includes a secure link to the custodian portal.

In the portal, custodians can acknowledge their participation in a hold, answer questionnaires, view all active projects they're associated with, and easily address any other outstanding tasks. For more information, see Custodian portal.

Relativity includes different templates to choose from when creating this communication. You can include merge fields and instructions tailored to your organizations.

Note: When using a General Hold Notice communication, the [PORTALLINK] merge field is no longer required when the Acknowledgment Required field is No and there is no questionnaire.

Alert group

The alert group notice is sent to a pre-identified group of employees within an organization to notify that they are potentially involved in a legal hold. The alert groups may include human resources, legal, and IT or any group of individuals impacted by the custodian’s response to the question.

Their involvement, and the release of the alert communication, is based on custodians’ questionnaire responses. For example, if a response involves another individual or group in the alert group, the alert notice is sent. This communication is a custodian notification that includes a mention of future communications. For more information, see Sending questionnaires.

Email acknowledgement

The email acknowledgement lets a custodian acknowledge participation in the legal hold without having to visit the Custodian Portal. The acknowledgement via email includes an in-depth description of the legal hold and a link for the custodian to click to acknowledge that the legal hold has been received.

The response to the acknowledgement email is sent to the email address listed in the Reply to Email Address field in the email settings. For more information, see Adding email settings.

Release notice

The release notice is sent to a custodian when they are no longer needed in the legal hold. This is the final communication to a custodian and no further communications are sent from that legal hold project. The release notice states that the matter does not include any other pending legal holds that apply to the custodian, including any separate legal holds that may relate in any way to the same subject matter.

Using the editor window

Use the rich text editor window to compose portal content, emails, reminders and escalations, and BCC emails. The rich text editor provides support for hyperlinks, images, and tables, and is optimized for copying and pasting from Microsoft Word to customize your communications to custodians. You can customize text with the editor icons and utilize email merge fields to insert field values in Legal Hold. See Using the rich text editor.

Note: When adding embedded links in the text editor, you must prefix the links with http or https, otherwise the text editor treats the link as relative to the current page. For example, but "http://google.com" is a valid, absolute link and will render correctly as a rich text field.

Hyperlinks

To add hyperlinks in the editor window:

• Relativity requires HTTPS links only. Links need to follow the following format: start with https://, and can include forward slashes, periods, and alphanumeric characters. For example, <a href=”https://www.relativity.com/customers/” >Relativity Customers</a>.
• To add a link, you must be in the Legal Hold admin group, or a group that has the following permissions:
  For more information, see Instance Details tab.

  • Object Security - InstanceSettings—View
  • Admin Operations - View Admin Repository

• To add a link, you must update the DomainNameWhiteListUrls instance setting. It's a semicolon-delimited list of allowed domains. For example, "google.com;mozilla.org".

For more information, see Using the rich text editor.

Email merge fields

You can use email merge fields in the editor window to embed in a communication's subject line and body text, which translates into the corresponding Legal Hold field value upon sending. For example, if you type the merge field, [Communication.Name], using brackets, Legal Hold will translate that merge field to whatever value is in the Communication Name field in the Communication details tab.

One useful example for using merge fields is the Project.SubjectMatterStartDate. You can save this information in a project template so that you don't have to customize this information each time you create a project.

You can use email merge fields from the drop-down list in the editor window above the text to embed in a communication's subject line and body text, which translates into the corresponding Legal Hold field value upon sending. For example, the merge field Communication. Name would translate to the value in the Communication Name field in the Communication details tab.

Each communication has its own list of merge fields. The merge fields in one communication cannot be used in different types of communications. For example, adding a merge field from the Alert Notice communication list may not work in the Acknowledgement communication. Only use what's available in the Merge Fields drop-down menu.

Email merge fields are case insensitive, so if typing the keyword, you can enter the same merge field in different ways:

• [Custodian.FirstName]
• [custodian.firstname]
• [CUSTODIAN.FIRSTNAME]

Note: If you use a merge field that does not contain any content in the field value, the merged field displays as the merge field name in the communication. For example, the merge field displays in the communication as "Custodian.FirstName" instead of "Jane".

Note: As of the Legal Hold 3.3.1 release, the [ID] merge field is no longer supported. Also note that the [PHONE] merge field is now [PHONENUMBER] and the [CURRENTTITLE] merge field is now [JOBTITLE]. If you were using any of these merge fields in communications prior to upgrading, be sure to manually update or remove them.

Email merge fields list
